About the Lab

This laboratory will give an opportunity to the students and researchers for carrying out research on Micromanufacturing technologies using mechanical micro-machining.

Facilities

The laboratory is equipped with the some of the latest state-of-the-art facilities as follows:
• an ultra-precision 5 axis CNC Micro-machining centre (positional accuracy of ± 0.5 µm, surface finish Ra < 1 µm),
• Laser measuring system: Tool measurement,
• Touch probe system: Workpiece measurement,
• High speed Spindle options: 500-50,000 rpm and 60,000-160,000 rpm oil-air lubricated,
• Lubrication: Oil mist / Flood,
• an optical camera system for inspection of micro-tools with enhanced zoom range for 40-450x magnification,


as well as various software packages such as,

• CNC Simulator Heidenhain ITNC 530,
• CAD modeling software (SolidWorks, CATIA),
• Software for CAD/CAM based Part Programming (CAMWorks, SpectraCAM, SpectraCAD Engraver)



Video Gallery

Photo Gallery


         5 axis CNC Micro-machining centre at IIT Kharagpur



Optical camera system for inspection of micro-tools at IIT Kharagpur


Directions to the Lab
The laboratory is located on the Ground floor of the Workshop Training Extension Building of the Mechanical Engineering Department.

Contact Info
Dr. Sankha Deb
Associate Professor,
Mechanical Micro-machining Laboratory,
Department of Mechanical Engineering,
Indian Institute of Technology Kharagpur,
Kharagpur - 721302, INDIA.
Phone: +91-3222-282912
Email: sankha.deb@mech.iitkgp.ernet.in
